The colorimeter is an instrument used to measure the color of a substance, using the RGB color system. This system uses three primary colors: red, green, and blue. Similarly, it measures the intensity of each and then combines them to create a color. It has an accuracy of 0.01%. This is very useful for chemists, as they can use the colorimeter to measure small amounts of substances.
The colorimeter is also used in medicine, where doctors use equipment to measure the color of blood and other body fluids to detect diseases and medical conditions. It is a very useful instrument that is used in many fields. It is precise, easy to use and available in many sizes and shapes. That said, the Kalstein colorimeter states that the absorbance of a solution is proportional to the concentration of the solution, which consists of a light source, a filter, a detector and a reading device.
Kalstein using autonomous core technology research and development of A portable light color difference instrument, is the high level in spectral architecture color difference instrument, in addition to ensure accurate relative Δ E at the same time, also to ensure the accuracy of the absolute value of L, A and B for A long time, anytime, anywhere can pass the international standards and national standards of measurement.
Using the built-in silicon photodiode array (double row 24) sensors, import the whiteboard, repetitive Δ E * ab easily control within 0.1, both measurement speed and convenience of operation, no need to connect the computer or software can quickly judging color difference measurement, 8 mm diameter meet plastic electronics, paint and ink, textile printing and dyeing, printing, such as the ceramic industry accurate color difference of production and the quality control.
Precision colorimeter features with 8/d structure that is very precise. 8mm measurement...
Kalstein team concentrates on customer needs and develops a new serie YR05509 // YR05513 with high precision & low cost & two apertures, and Φ4mm tip...
YR05516 // YR05519 is Kalstein using autonomous core technology research and development of A portable light color...
Kalstein team concentrates on customer needs and develops a new serie YR05509 // YR05513 with high precision & low cost & two apertures, and Φ4mm tip...
| Model | YR05506 | YR05507 | YR05508 |
| Illuminating/Viewing Geometry | 8/d | 8/d | 8/d |
| Measuring Aperture | Φ8mm/Φ4mm | Φ8mm | Φ8mm |
| Detector | Silicon photoelectric diode | Silicon photoelectric diode | Silicon photoelectric diode |
| Color Space | CIEL*a*b*C*h* CIEL*a*b* CIEXYZ CIERGB CIEL*u*v* CIEL*C*h Yellowness & Whiteness Color Fastness | CIEL*a*b*C*h* CIEL*a*b* | CIEL*a*b*C*h* CIEL*a*b* |
| Color Difference Formula | △E*ab △L*a*b* △E*C*h* △ECIE94 △Ehunter | △E*ab △L*a*b △E*C*h | △E*ab △L*a*b △E*C*h |
| Light Source | D65 D50 A | D65 | D65 |
| Light Source Device | LED blue light excitation | LED blue light excitation | LED blue light excitation |
| Errors Between Each Equipment | ≤0.40ΔE*ab | ≤0.40ΔE*ab | ≤0.50ΔE*ab |
| Storage | 100pcs standards 20000pcs samples | 100pcs standards 20000pcs samples | 100pcs standards 20000pcs samples |
| Repeatability | Standard deviation within ΔE*ab 0.06 | Standard deviation within ΔE*ab 0.07 | Standard deviation within ΔE*ab 0.08 |
| Average of 30 measurements of standard white plate | Average of 30 measurements of standard white plate | Average of 30 measurements of standard white plate | |
| Weight | 500g | 500g | 500g |
| Dimension | 205×70×100 mm | 205×70×100 mm | 205×70×100 mm |
| Power source | Rechargeable lithium-ion battery 3.7V@3200mAh | Rechargeable lithium-ion battery 3.7V@3200mAh | Rechargeable lithium-ion battery 3.7V@3200mAh |
| Lamp Life | 5 years, more than 1.6 million measurements | 5 years, more than 1.6 million measurements | 3 years, more than 1 million measurements |
| Charging Time | 2 hours (first time 8 hours–100% electricity) | 2 hours (first time 8 hours–100% electricity) | 2 hours (First time 8 hours–100% electricity) |
| Measurement Times Before Recharging | More than 3000 times | More than 3000 times | More than 3000 times |
| Operating Temperature/Humidity Range | -10~40℃, relative humidity 0~85% with no condensation | -10~40℃, relative humidity 0~85% with no condensation | -10~40℃, relative humidity 0~85% with no condensation |
| Data Interface | USB | USB | USB |
| Extended Aperture (optional) | Φ8mm extended aperture, available for measuring concave surface | – | – |
| Printer (optional) | Miniature thermal printer | Miniature thermal printer | Miniature thermal printer, Powder Test Box |
Colorimeters are instruments used to determine the exact composition of a color, because they have the ability to provide...
Colorimeters are instruments used to measure and analyze colors. Specialized color measurement equipment, using...
The Colorimeter is an optical device that can be used to measure the absorption of a chemical at a specific wavelength...
The colorimeter is an instrument used to determine the color of a sample. It is based on a photometer, which measures the...
Anions are negatively charged ions, are in solution and are attracted to the anode, or positive electrode. To identify anions...
The region became culturally distinguishable from the Lowlands from the later Middle Ages into the modern period.
In analytical chemistry, a colorimeter is an instrument used to measure the concentration of a solution by measuring the...
A colorimeter is a tool used to determine the concentration of a chemical in a sample. It is a portable and compact device that can be used both in the laboratory and in the field. Therefore, in Kalstein we have the optimal colorimeter that measures the absorbance of...
To know the price of the Colorimeter we invite you to send us an email with your request through the contact form.
The delivery time of your Kalstein product will depend on the following:
- Delivery Time (Air): 15-30 days.
- Delivery Time (Maritime): 45-60 days.
- Delivery Time (Air): 30-60 days.
- Delivery Time (Maritime): 60-90 days.
You can make your purchase through:
All Kalstein equipment has a 1-year warranty against manufacturing defects. The warranty does not cover damage caused by poor installation or operation by the user, transport defects or by uses other than those specified by the manufacturer. Warranty excludes electrical or consumable parts. For more information visit our “terms and conditions” by clicking HERE
At Kalstein, we provide our customers with induction and technical support through new online methods. You can visit our induction videos, technical assistance and guidance provided by a Kalstein team through our YouTube channel (Kalstein English). HERE
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
