ECG-Digital Electrocardiograph
An electrocardiograph is a medical instrument that records the electrical activity of the heart. Physicians use this electrical activity to measure and evaluate the overall functioning of the heart. Specifically, this tool can detect if there is an irregular heart rhythm, if the walls of the heart are too thick, or if the heart is working too hard, among other problems.
Types of ECG-Digital Electrocardiograph that the Medical sector may need
12-lead ECG monitor USB / RS232 interface YR05160
The 12-channel ECG machine is an electrocardiograph that can collect 12-lead ECG signals simultaneously and print ECG waveforms with thermal printing...
6 Channel Smart Hospital ECG Manufacturing Machine Monitoring Dynamic Holter ECG Systems YR05161
This new 6-channel YR ECG will bring you the power of advanced and easy-to-use...
YR05158 12 Channel Electrocardiograph Touch Screen ECG Machine
As the name suggests, the 3-channel ECG machine prints 3 waveforms / channels at a time. On 3-channel machine...
YR05159 12 Channel 12 Lead 6 Channel Medical Ecg Machine
The 12-channel ECG machine is an electrocardiograph that can collect 12-lead ECG signals simultaneously and print ECG waveforms with thermal printing...
Our Best Selling ECG-Digital Electrocardiograph
The 12-channel ECG machine is an electrocardiograph that can collect 12-lead ECG signals simultaneously and print ECG waveforms with thermal printing system. The EKG is commonly used to detect abnormal heart rhythms and to investigate the cause of chest pains. An EKG records the electrical activity of the heart. The heart produces small electrical impulses that travel through the heart muscle to cause the heart to contract. These impulses can be detected by the ECG machine.
| Model | YR05159 |
| Elements | specification |
| Characteristics | 7 ″ screen,
touch screen Supports Ecg analysis capabilities |
| Guide | 12 standard conductors |
| prospect acquisition | synchronously 12 leads |
| Input circuit | Floating; Defibrillator protection circuit |
| Input impedance | ≥50MΩ |
| Input circuit current | ≤0.0.05μA |
| Record mode | Automatic: 3CH × 4 + 1R, 3CH × 4,
3CHx2 + 2CHx3,3CHx2 + 2CHx3 + 1R, 6CHX2; Manual: 3CH, 2CH, 3CH + 1R, 2CH + 1R; Rhythm: any selectable lead. |
| Filter | EMG filter: 25Hz / 30Hz / 40Hz / 75Hz / 100Hz / 150Hz DFT filter: 0.05Hz / 0.15Hz AC filter: 50Hz / 60Hz |
| CMRR | > 100dB |
| Patient current leak | <10μA |
| Input circuit current | <0.05 µA |
| Frequent response | 0.05Hz ~ 150Hz (-3dB) |
| Sensitivity | 2.5mm / mV, 5mm / mV, 10mm / mV, 20mm / mV |
| Anti-baseline drift | Automatic |
| Constant time | ≥3.2s |
| Noise level | <15μVp-p |
| Paper speed | 12.5mm / s, 25mm / s, 50mm / s |
| Recording mode | Thermal printing system |
| Paper specification | Sun-7031: 80mm x 20m paper roll Sun-7062: 120mm x 20m paper roll |
| LCD screen | 7 ″ graphic LCD |
| Safety rating | IEC60601-1 class I, type CF |
| Power supply | AC: 100 ~ 240V, 50 / 60Hz, 30VA ~ 100VA |
| Fuse | AC220V ± 10% 2 * Φ5 × 20mm, T2A / 250V AC time delay |
Model Catalog for Sale ECG-Digital Electrocardiograph
Guides to becoming an expert in Electrocardiograph ECG-Digital
Crucial Role of the Electrocardiograph in the Diagnosis and Treatment of Heart Disease
As technology and medical science advance, healthcare professionals have more tools at their disposal to assist them in the detection...
How Electrocardiographs Improve Patient Management in Cardiac Care Units
The technological and medical innovations of the 21st century have enabled a significant increase in the efficacy of cardiovascular...
The Revolutionary Contribution of the Electrocardiograph in the Identification of Cardiac Problems
The electrocardiograph, also known as the ECG or EKG, is a vital tool that records the electrical activity of the heart. It arose from scientific...
Importance of Electrocardiographs in Cardiovascular Health Examinations
In a world where every heartbeat counts, electrocardiographs have become crucial equipment for cardiovascular diagnostics...
Videos of Electrocardiograph ECG-Digital in operation
In this section you can find videos of our ECG-Digital Electrocardiograph in operation, packaged, receiving service, etc.
Electrocardiograph ECG-Digital
The use of electrocardiographs in cardiac care units has been monumental in terms of improving patient management and care. A vital aspect of this improvement centers on providing physicians with a deep and rapid understanding of the patient’s cardiac situation. This enables physicians and nurses to make accurate, data-driven decisions, thereby improving diagnostic efficiency and reducing emergency response time.
Frequently Asked Questions about ECG-Digital Electrocardiograph
How to know the prices of ECG-Digital?
To know the price of the ECG-Digital Electrocardiograph we invite you to send us an email with your request through the contact form.
What are the delivery times of the ECG-Digital Electrocardiograph?
- If the equipment of your interest is in stock or if it must be manufactured.
- The type of freight you have chosen, this may be; air or sea.
How to purchase the ECG-Digital Electrocardiograph?
- By email: [email protected]
- By telephone: +33 (0) 1 78 95 87 02
- E-commerce: Via Kalstein's official website in your country.
How does the warranty work?
Can I request a quote online?
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
