Electrosurgical Unit
The electrosurgical unit, also known as electroscalpel, is a medical equipment that uses electrical phenomena that generate heat; in order to coagulate, fulgurate, dry or cut tissues, depending on the parameters established by the medical operator. Heat generation is achieved through the passage of an oscillatory electric current, concentrated in a small area.
The importance of the use of electrosurgical units in the operating room is that these devices are nowadays considered essential instruments in these places, because they produce precise incisions without the need to exert pressure on the tissues, as well as allow easy access to difficult or compromised areas, offer excellent comfort in the lifting of hypertrophic tissues, facilitate the containment of hemorrhages and the healing of gingival tissues with the correct use, and also prevent the infiltration of microorganisms in the incision line.
Types of Electrosurgical Unit tha the Medical Sector may need
Electrosurgical Generators YR02145 // YR02146
YR electrosurgical series generator is a versatile electrosurgical unit for all around surgical procedures through all types of tissue...
Electrosurgical Generators Unit //YR02144
Electrosurgical generator combines versatility and safety, for all general electrosurgical procedures such as cutting and coagulation in clinics...
Electrosurgical Generators Unit //YR02147
YR electrosurgical generator series is a reliable electrosurgical unit for loop electrosurgical excision procedure (LEEP) in gynecology...
Our Best Selling Electrosurgical Unit
- The electrosurgical generator ensures a smooth cut through all types of tissue.
- It performs automatic recognition of the return electrode, either solid or spilled.
- It offers program memory functions and automatic current monitoring.
- The argon module is optional to improve cutting and coagulation.
- Optional adapter for laparoscopic and thoracoscopic application.
- The electrosurgical generator has an easy-to-use interface.
- It has an isolated output, all floating.
The electrosurgical unit is a medical equipment capable of transforming electrical energy into heat to cut or coagulate tissues and cauterize them simultaneously, using currents that develop at high frequencies usually above 200,000 Hz. In other words, this equipment is responsible for generating high-frequency alternating current from low-frequency electrical currents, in order to achieve a desired thermal effect on a biological tissue.
Model | YR02144 | |||
Monopolar | ||||
Cutting mode | Max. Output power (watts) | Load (ohms) | Open circuit Vp-p | Crest factor |
Pure | 400 watts | 500 Ω | 2,300v | Sun May 01 2022 00:00:00 GMT + 0200 (Central European Summer Time) |
Mix 1 | 300 watts | 500 Ω | 2,700v | Sun Jan 02 2022 00:00:00 GMT + 0100 (Central European Standard Time) |
Mix 2 | 200 watts | 500 Ω | 3,200v | Mon May 02 2022 00:00:00 GMT + 0200 (Central European Summer Time) |
Mix 3 | 150 watts | 500 Ω | 3,700 v | Mon Jan 03 2022 00:00:00 GMT + 0100 (Central European Standard Time) |
Coagulation mode | ||||
Point | 120 watts | 500 Ω | 5,600v | Thu Jan 06 2022 00:00:00 GMT + 0100 (Central European Standard Time) |
Gentle | 120 watts | 500 Ω | 3,400 v | Thu Jan 06 2022 00:00:00 GMT + 0100 (Central European Standard Time) |
Spray | 120 watts | 500 Ω | 8,500 v | Tue Mar 08 2022 00:00:00 GMT + 0100 (Central European Standard Time) |
Bipolar | ||||
Cutting mode | ||||
Standard | 70 watts | 200 Ω | 1,450v | Sun May 01 2022 00:00:00 GMT + 0200 (Central European Summer Time) |
Coagulation mode | ||||
Standard | 70 watts | 500 Ω | 240v | Sun May 01 2022 00:00:00 GMT + 0200 (Central European Summer Time) |
Precise | 70 watts | 200 Ω | 360v | Sun May 01 2022 00:00:00 GMT + 0200 (Central European Summer Time) |
Connecting accessories and supplies | ||||
Finger pencil | two | |||
Foot switch pencil | one | |||
Patient return electrode | one | |||
Foot switch | one | |||
Ac power supply | one | |||
Potential equalization | one | |||
Power characteristic | ||||
Rate frequency | 512 kHz (110 / 240vAC, 60 / 50Hz) | |||
Isolated output | YES | |||
Quantitative visualization of the contact area | YES, for the «Split» type of neutral electrode | |||
Contact area indicator lamp | 10 lamps (one for 10% contact), alarm beep and flash if contact <20% | |||
Definition of Solid / Split Neutral Electrode | YES, the ‘Split’ or ‘Solid’ indicator light comes on | |||
Adjustable alarm volume | YES | |||
Operating duty cycle | 10 seconds ON, 30 seconds OFF | |||
Cooling method | Convection | |||
Regulation | ||||
Type According to EN 60601-1 | CF | |||
Protection class according to EN 60601-1 | class I | |||
Classification acc. According to MDD 93/42 / EEC | IIb | |||
Physical | ||||
Dimension (WxDxH) | 460 x 410 x 160 mm | |||
Weight | 11.2 kg |
Electrosurgical Unit Analysis for the Medical Sector
What is the importance of an electroscalpel?
An electroscalpel is a medical device of electrical origin used in operating rooms with the aim of cutting or coagulating ...
Where is the electrocautery placed?
An electrocautery is an electronic equipment that uses radio frequency to coagulate, desiccate, and cauterize blood...
Electro surgicalunit or electroscalpel – advantages
The electroscalpel is a device that is present in approximately 80% of surgical processes, through electrical ...
Care when using an electrosurgical unit
The electrosurgical unit is a medical equipment capable of transforming electrical energy into heat to cut or coagulate...
Electrosurgical Unit Model Catalog on Sale
Guides to becoming an expert in Electrosurgical Unit
What are the general principles of Electrosurgery?
Electrosurgery is a surgical subspecialty where high frequency electrical energy is used on any biological tissue, in order to...
Electrosurgery, what is it and how does it work?
The electrosurgery unit, or electrosurgery, is a medical device that uses electrical phenomena to produce heat; Its...
Electrosurgical unit for hospitals and clinics
The electrosurgical or electrosurgical unit, also called an electrosurgical unit, is a medical device that uses electrical...
What is the importance of an electrosurgery or Electrosurgical unit?
An electrosurgery unit or electrosurgical unit is a medical device that transmits energy in a controlled manner to living tissue for surgical purposes in order to cut, coagulate, fulgurate, and desiccate tissues...
Frequently Asked Questions about Electrosurgical Unit
How to know the prices of the Electrosurgical Unit?
To know the price of the Electrosurgical Unit we invite you to send us an email with your request through the contact form.
What are the delivery times of the Electrosurgical Unit?
What are the delivery times of the Electrosurgical Unit?:
- If the equipment of your interest is in stock or if it must be manufactured.
- The type of freight you have chosen may be either air or sea.
- Equipment in stock:
– Delivery Time (Air): 15-30 days.
– Delivery Time (Maritime): 45-60 days.
- Equipment not in stock:
– Delivery Time (Air): 30-60 days.
– Delivery Time (Maritime): 60-90 days.
How to make a purchase of the Electrosurgical Unit?
You can purchase through:
- By email: sales@kalstein.eu
- By phone: +33 (0) 1 78 95 87 02
- E-commerce: Via Kalstein's official website in your country.
How does the warranty work?
At Kalstein, we provide our customers with induction and technical support through new online methods. You can visit our induction videos, technical assistance and guidance provided by a Kalstein team through our YouTube channel (Kalstein English). HERE
