YR01829 Benchtop Conductivity Meter

Manufacturer: Kalstein

Description

Classical benchtop conductivity meter, 1 to 3 points calibration, setup menu contains 6 options. The meter is suitable for daily testing and controls, accuracy: 1% F.S.

Features:

• Classical benchtop conductivity meter is equipped with a backlit LCD display.

• 1 to 3 points calibration with automatic recognition for conductivity standards.

• Automatic temperature compensation corrects conductivity measurment to reference

temperature.

• Auto-Read function senses and locks the measurement endpoint.

• Setup menu allows setting the number of calibration points, cell constant, temperature

coefficient, auto-power off, etc.

• Reset function automatically resumes all settings back to the factory defaults.

Applications:

• Water and wastewater treatment

• Research and educations

• Chemical industry and other laboratory applications

Model YR01829
Conductivity
Range 0.01 to 20.00, 200.0, 2000µS/cm, 20.00, 200.0mS/cm
Resolution 0.001, 0.01, 0.1, 1
Accuracy ±1% F.S.
Calibration Points 1 to 3 points
Calibration Solutions 10µS, 84µS, 1413µS, 12.88mS, 111.8mS
Temperature
Range 0 to 105°C/32 to 221°F
Resolution 0.1°C/0.1°F
Accuracy ±1°C/±1.8°F
Offset Calibration 1 point
Calibration Range Reading ±10°C
General Specifications
Temperature Compensation 0 to 100°C/32 to 212°F, manual or automatic
Temperature Coefficient Linear (0.0 to 10.0%/°C)
Reference Temperature 25°C
Cell Constant K=0.1, 1, 10 or custom
Hold Function Manual or auto-endpoint
Connector 6-pin nimi-DIN, 3.5mm jack socket
Display Custom LCD (120×60mm)
Power DC9V, using AC adapter, 220V/50Hz
Dimensions 210(L)×205(W)×75(H)mm
Weight 1.5kg
Order Code Accessories
YR01829
CON-1 conductivity electrode
TP-10K temperature probe
Conductivity standards 84µS/cm, 1413µS/cm, 12.88mS/cm
DC9V power adapter
YR01829-2
CON-0.1 conductivity electrode
CON-1 conductivity electrode
TP-10K temperature probe
Conductivity standards 84µS/cm, 1413µS/cm, 12.88mS/cm
DC9V power adapter
YR01829-1
CON-1 conductivity electrode
CON-10 conductivity electrode
TP-10K temperature probe
Conductivity standards 84µS/cm, 1413µS/cm, 12.88mS/cm
DC9V power adapter

Additional information

Weight 1,5 kg
Dimensions 32 × 27 × 20 cm
Modelo

YR01829, YR01829-1, YR01829-2
