Description
Mechanical ventilation is a way of providing respiratory support for animals who are unable to maintain ventilation or oxygenation on their own. It is used for a wide variety of conditions. Mechanical ventilation does not cure any disease, but it does support lung function to allow time to treat the underlying problem.
Features
- Respiration Mode: IPPV, SIMV, Manual
- Waveform: P-t (Pressure-time), V-t (Volume-time)
- Monitoring Parameters: TV (tidal volume), MV (minute ventilation), AP (airway pressure)
Technical Specifications
Model | YR06102 |
Respiration mode | IPPV, SIMV, MANUAL |
Display | 5.5′ SNT screen |
Waveform | P-t, V-t |
Tidal volume | 0,50ml~1600ml |
Respiratory frequency | 1 to 65 BPM |
I:E ratio | 8:1~1:8 |
Alarm parameters | High pressure alarm,Low pressure alarm,O2 source lost alarm ,AC power lost alarm |
High Pressure alarm limit | 20~60cmH2O |
Low Pressure alarm Limit | 0~20cmH2O |
Monitor Parameters | Tidal volume, MV, Ppeak, PEEP, respiratory frequency, I:E ratio |
Safety valve pressure limit | 6Kpa |
