Description
400mA HF generator
LCD touch-screen Console
Collimator
X-ray tube
Animal table
JPI grid
Flat panel detector
Imaging workstation computer and LCD monitor
Technical Specifications
Model | YR06164 |
Maximum output power | 32kW |
Range of tube current | 32~400mA |
Tube voltage range of radiography | 40kv~125kv |
Loading time | 10~5000ms |
mAs range | 0.32~400mAs |
Input voltage range | AC 220V±22V |
Max. Tube voltage | 120kV |
Focus | Small focus:1.0mm Large focus:2.0mm |
Anode speed | 2800 r/min |
CPU | ≥2.8GHz |
Memory | 4GB |
Disk Capacity | 500GB |
Medical LCD | 19” LCD |
