Description
- LED digital display can show the setting parameters directly.
- The instrument adopt de motor, use microcomputer to contrai speed, to achieve high accuracy, and not affected by voltage fluctuations.
- The instrument is designed with low speed start, avoiding sudden high speed may cause liquid spilt.
- The instrument can automatically operate according to the original settings after power gel normal from sudden eut off.
- The instrument can realize fault self-diagnosis by sound and light to prompt the fault location.
- Each parameter value can be modified in real lime under running state.
- When overloaded, the instrument will automatically stop, ensuring the life and safety of the instrument.
- Wide voltage range, can be used in the range of AC90-260v.
Technical Specifications
Model | YR05794 | YR05795 | YR05796 | YR05797 | YR05798 | YR05799 | YR05800 | YR05801 |
shaking mode | orbital/
convolution |
liner /
reciprocation |
Rocking | waving /
three dimensional |
||||
control | Microcomouter PID control | |||||||
displav | LED diqital display | |||||||
amplitude | Ø30 | 30mm | 25mm | 3-15°/manual | ||||
frequency (rpm/min) | 15-240 | 15-90 | ||||||
sensitivity (rpm) | +2 | |||||||
timmer | 0-99hours
59minutes |
|||||||
trav size(mm) | 250x
230 |
320x
265 |
250x
230 |
320x
265 |
250x
230 |
320x
265 |
250x
230 |
320x
265 |
tray number | 1 | |||||||
overall size/mm) | 270x295x
160 |
330x480x
160 |
270x295x
160 |
330x480x
160 |
270x295x
170 |
330x480x
220 |
270x295x
170 |
330x480x
180 |
Power | 30W | |||||||
power supply | AC 90-260V, 50-60HZ | |||||||
ambient temperature | -10 °C-65 °C |
