Description
The Benchtop pH/DO Meter YR06383 is the ideal solution for laboratories and research facilities seeking precision in pH and dissolved oxygen measurements. Featuring a 7-inch colored capacitive touch screen with high resolution and sensitivity, this device ensures accurate readings every time. With capabilities such as automatic calibration, ATC, data storage, and wireless printing, the YR06383 offers both versatility and ease of use. It supports wireless Bluetooth printing and can transfer data to a PC or mobile device in real time. Store up to 1000 sets of test data, which can easily be exported to Excel via USB. Whether you’re working in pH mode with auto recognition of 25 buffers or in DO mode with advanced compensation functions, this benchtop meter meets the demands of today’s rigorous testing environments.
Market Price
The Benchtop pH/DO Meter YR06383 is competitively priced, with market averages typically ranging from $1200 to $2000. Due to its advanced features and reliability, it offers excellent value for professionals seeking high performance and accuracy.
Frequently Asked Questions
Is the YR06383 compatible with different calibration standards? Yes, it supports Europe & USA, NIST, and China standards for buffer solutions.
Can I connect the device to my computer? Yes, it has USB and Bluetooth connectivity options for seamless data transfer.
Advantages and Disadvantages
Advantages: High precision, user-friendly interface, extensive data storage, and versatile connectivity options. Disadvantages: Initial setup may require some time for calibration and settings adjustments.
Product Use in the Field
In practical settings, the YR06383 is used extensively for conducting accurate chemical analyses in laboratories, ensuring consistent results in both environmental and industrial applications. Its quick response time minimizes wait periods, thereby improving efficiency.
Recommendations
For optimal performance, regular calibration and maintenance of the electrodes are recommended. Ensure that the wireless and manual calibration settings are regularly updated for precise measurements.
Features
- 7-inch colored capacitive touch screen with high resolution.
- Automatic calibration with ATC.
- Ability to store and transfer up to 1000 data sets.
- Bluetooth and USB connectivity for data export.
- Smart electrode status display.
- Polarographic DO electrode with short polarization time.
Technical Specifications
| Model | YR06383 | |
| pH | Measuring range | (-1.999 ~ 19.999)pH |
| Resolution | 0.1/0.01/0.001 pH | |
| Accuracy | Electrode: ±0.002 pH, Meter: ±0.01 pH | |
| Auto calibration | 1, 2, 3 point | |
| Buffer | Europe & USA, NIST, China standards | |
| Input current | ≤1×10-12 A | |
| Input impedance | ≥3×1012 Ω | |
| Stability | ±0.002 pH/3h | |
| Temp. compensation | (0 ~ 100)ºC, auto or manual | |
| mV | Measuring range | -1999.9mV ~ 0 ~ 1999.9mV |
| Resolution | 0.1 mV | |
| Accuracy | ±0.03% FS | |
| DO | Measuring range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp compensation | (0 ~ 45)ºC, auto | |
| Salinity compensation | (0 ~ 45) ppt, auto | |
| Pressure compensation | (80 ~ 105) kPa, auto | |
| Auto calibration | Air saturated by water; water saturated by air | |
| Electrode type | Polarographic | |
| Temp. | Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
| Other | Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB, RS232, Bluetooth | |
| Ambient Temp. | 15 ~ 30 ºC | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 240×170×70mm/600g | |
| Shipping Size/G.W. | 470x430x85mm/2.6kg | |
