Automatic Veterinary Chemistry Analyzer YR06168

ManufacturerKalstein

Description

The Automatic Veterinary Chemistry Analyzer YR06168 is a cutting-edge tool designed specifically for veterinary clinics and research centers. This analyzer features specialized veterinary software that caters to 8 pre-determined animal settings and allows for unlimited user-defined animal configurations. With a throughput capacity of up to 100 tests per hour, it significantly reduces labor through simple programming and genuine walk-away operation. Its open reagent system can easily be converted to a closed one upon request, while micro-volume capabilities for both sample and reagent handling make it versatile and efficient. Additionally, the device supports multi-language software, making it accessible to users worldwide.

Market Price

The market price for veterinary chemistry analyzers like the YR06168 usually ranges from $15,000 to $15,800. This competitive pricing reflects its advanced features and the technological advantages it offers to veterinary professionals.

Frequently Asked Questions

What type of maintenance does the analyzer require?
The YR06168 requires minimal maintenance, focusing mainly on the cleanliness of the cuvettes and regular software updates.

Can the analyzer be used for emergency diagnostics?
Yes, its rapid throughput and ease of programmability make it ideal for urgent testing scenarios.

Advantages and Disadvantages

The key advantages of the YR06168 include its high throughput, flexible operation settings, and adaptability to various testing needs. However, a potential disadvantage could be its initial investment cost, though this is offset by its operational efficiency and broad functionality.

Product Use in the Field

In practice, the Automatic Veterinary Chemistry Analyzer YR06168 is utilized for routine and specialized diagnostic testing within veterinary laboratories. Its ability to switch between sample and reagent positions enhances workflow efficiency, and the device is particularly beneficial in busy clinics with a high volume of tests.

Recommendations

For optimal performance, it is recommended to regularly calibrate the analyzer and utilize the product’s software updates. Proper storage of reagents at recommended temperatures will also ensure accurate testing results.

Features

  • Specialized veterinary software
  • 8 pre-determined animals settings and unlimited number of user-defined animal settings
  • Throughput up to 100 tests per hour
  • Labor saving, simple programming and real walk-away operation
  • Reagent open system, closed system on request
  • Micro-volume for sample and reagent
  • Sample position and reagent position switchable
  • Multi-language software supported

Technical Specifications

Model YR06168
Reagent volume:
R1: 180-450uL, 0.1uL adjustable R2: 3-250uL, 0.1uL adjustable
Reaction position: 90 cuvettes, 10 cuvettes / strip
Cuvette: 5mm optical length
Reaction volume: 180-500 uL
Reaction temperature: 37°C
Lamp: Halogen lamp
Absorbance range: 0-3.500Abs
Wavelengths: 8 wavelengths of 340-700 nm
Resolution: 0.0001Abs
Power supply: DC 110V/220V, 50HZ/60Hz
Dimension L*W*H (mm): 630*480*510
Net weight: 70kg
Sample volume: 3~45uL, 0.1uL adjustable
Positions for reagents 26
Refrigerated temperature: 4-15°C

Additional information

Weight 75 kg
Dimensions 107 × 62 × 82 cm
