Veterinary Operating Table YR06694

The YR06694Veterinary Operating Table is a high-end surgical workstation specifically designed for veterinary clinics and animal surgery centers that require precise thermal control. Its primary feature is the integrated thermostat system, which allows patients to be maintained at an optimal temperature during prolonged procedures, effectively reducing the risk of intraoperative hypothermia. This equipment is aimed at veterinary professionals seeking durability and advanced functionality. Its V-top design and full 304 stainless steel construction guarantee a sterile, corrosion-resistant, and easy-to-clean environment that meets the strictest clinical hygiene standards.

Design and Technology (or Functionality)

The YR06694 combines mechanical robustness with intelligent thermal control technology:

• Automatic Thermostat System: Allows for precise adjustment of the surface temperature between 0 and 60 degrees Celsius to suit the needs of each species and procedure.
• Smooth Electro-Hydraulic Lifting: Equipped with an oblique lifting support and a touch switch, the table offers fluid ascent and descent (from 450 mm to 1000 mm) with a firm lock for maximum stability.
• Safety Management: Includes integrated leakage protection and high-temperature protection systems, ensuring safe use for both the operator and the patient.
• Surface Versatility: The table features a movable stainless steel mesh, allowing the user to choose between a flat mesh or an arc mesh configuration depending on the type of intervention.
• Industrial Strength: Manufactured from high-quality 304 stainless steel, an anti-corrosive and acid-resistant material that ensures a long service life and protection against oxidation.

Frequently Asked Questions (FAQ)

• Is it difficult to set the desired temperature? No, the system features an intuitive control panel that allows the thermostat to be adjusted at will. The equipment automatically maintains the temperature once it is set.
• How stable is the table at its maximum height? Thanks to its oblique support design and its 90 kg net weight, the table maintains a firm lock and exceptional stability even when elevated to its maximum of 1 meter.
• Is the heating surface safe for direct contact? Yes, the heating system is fast but regulated by a high-temperature safety protection to prevent accidental burns; however, the use of standard surgical drapes is always recommended.

Advantages and Disadvantages

Advantages:

• Thermal Control: Ideal for long surgeries where maintaining body temperature is critical.
• Superior Hygiene: 304 stainless steel is the gold standard for preventing bacterial buildup and resisting harsh disinfectants.
• Ergonomic Operation: The touch switch and smooth descent minimize the physical effort of the veterinarian.
• Electrical Safety: Advanced leakage protection for peace of mind in wet environments.

Disadvantages:

• Electrical Dependency: Thermostat and lifting functions require a constant connection to the power grid.
• Weight: With a net weight of 90 kg, this table is not designed to be moved frequently once installed.

Field Use and Recommendations

This table is an indispensable centerpiece in veterinary operating rooms, emergency rooms, and intensive care units for small and medium-sized animals. It is particularly useful for abdominal and orthopedic surgeries. Practical Tip: To ensure optimal operation of the lifting system, avoid exceeding the recommended load and clean the surface after each use with non-aggressive solutions for 304 stainless steel to maintain its shine and anti-corrosive properties.

Technical Specifications

Parameter	characteristics
Model	YR06694
Surface Material	High-quality 304 Stainless Steel
Temperature Range	0 - 60 °C (Adjustable with automatic thermostat)
Lifting Range	450 mm - 1000 mm (Touch adjustment)
Table Type	V-top operating table
Mesh Configuration	Movable (Flat or Arc mesh selectable)
Safety Systems	Leakage and high-temperature protection
Resistance	Anti-corrosive, acid-resistant, and rust-proof
Packaging Dimensions	158 * 69 * 55 cm
Net Weight (N.W)	90 kg
Gross Weight (G.W)	115 kg
