Semi-automatic detection microtome YR416-1

The YR416-1 Semi-Automatic Detection Microtome offers maximum reliability, comfort, and precision for users. This microtome is a versatile tool designed for both paraffin sectioning and hard section techniques in biology, medicine, and industry. Its cutting motor allows for precise sections, ensuring excellent reproducibility. One of its most notable features is the adjustable cutting window. This window matches the sample size, with the preselected speed applied only within this window. This enables the precise sectioning of delicate specimens in a short amount of time. The section thickness ranges from 0.25 μm to 100 μm. Users can easily switch between fine and coarse sectioning during the process. The YR416-1 has a minimum cutting thickness setting of 0.25 μm and a horizontal feed of 28 mm. Its vertical sample stroke is 70 mm. It allows for sample holder rotation at any angle within 360 degrees. Additionally, the BladeHolder Base has a movement range of 0-60 mm (front to back), and the Blade Press Plate has a movement range of 0-23 mm. The sample orientation is XY-8°, and the maximum sample size is 70 × 70 mm. Its feed speed adjustment ranges from 1500 μm/s to 3500 μm/s, with a precision error of ±1%. It operates at AC 220V±10% 50Hz (standard model) or AC110V±10% 60Hz. Its power consumption is 100W. The dimensions are 575×420×330 mm (Width×Depth×Height), and it weighs 37 kg.

Market Price

The price of the YR416-1 Semi-Automatic Detection Microtome ranges between $5,000 and $8,000. This depends on the distributor and additional features required. Consequently, this price range makes it an accessible and competitive option for high-precision laboratory equipment.

Frequently Asked Questions

What is the minimum cutting thickness? The minimum cutting thickness is 0.25 μm. What is the maximum sample size it can handle? It can handle samples up to 70 × 70 mm. Is it possible to adjust the feed speed? Yes, the feed speed can be adjusted between 1500 μm/s and 3500 μm/s.

Advantages and Disadvantages

The YR416-1 Microtome offers several advantages. These include precision and reliability in each use, easy operation thanks to the adjustable cutting window, and the ability to handle both fine and coarse sections. However, it may present some disadvantages. New users may need an adaptation period, and the initial cost can be high for laboratories with tight budgets.

Field Use

The YR416-1 microtome is ideal for laboratories performing a high volume of sectioning. Its ergonomic design and simple operation allow technicians to prepare and process samples quickly and efficiently. Consequently, this improves productivity and result accuracy. In histology laboratories, its ability to maintain high stability and precision in sections is crucial for obtaining uniform and high-quality cuts.

Recommendations

To maximize the performance of the YR416-1, regular maintenance following the manufacturer's instructions is recommended. It is important to periodically calibrate the temperature sensors and clean the cutting components. This will keep the device in optimal condition. If you are looking to improve efficiency and precision in your laboratory, consider the YR416-1 Semi-Automatic Detection Microtome. Request a quote or generate an automatic quote through our Kalstein Plus platform. Discover how this device can transform your sample sectioning processes.

Technical Specifications

Model	YR416-1
Minimum Setting of Sectioning Thickness	0.25μm
Horizontal Feed	28mm
Vertical Specimen Stroke	70mm
Specimen Holder Rotation	at any angle within 360 degrees
Movement Range of the Base of BladeHolder Base	0-60mm (front to back)
Movement Range of the Blade Press plate	0-23mm
Specimen Clamp Rotation	at any angle within 360 degrees
Specimen Orientation	XY – 8°
Maximum Specimen Size	70×70mm
Feed speed adjust	1500μm/s ~ 3500μm/s
Precision Error	±1%
Working Voltage	AC 220V±10% 50Hz (standard model); AC110V±10% 60Hz
Power	100W
Dimensions	575×420×330 mm (W×D×H)
Net Weight	37kg
