Understanding Key Terminology for the YR06196 Digital Veterinary Intraoral X-ray System
The YR06196 Digital Veterinary Intraoral X-ray System represents a significant advancement in veterinary imaging technology. This article aims to clarify crucial technical terminology related to the YR06196, enabling users to fully utilize its capabilities and enhance their diagnostic processes.
Technical Data Table for YR06196
| Specification | Value |
|---|---|
| Model | YR06196 |
| Power Supply | 220V±10%, 50HZ, 1KVA |
| Tube Voltage | 70 kVp |
| Tube Current | 8 mA |
| Focus Size | 0.8 mm |
| Total Filtration | 2.5 mmAL |
| Exposure Time | 0.2-4s |
| Leak Radiation | Outside one meter ≤ 0.002Mg/h |
| Package Size | 152×57×26 cm |
| Net Weight | 57 kg |
| Chip Type | CMOS APS |
| Fiber Optic Plate | Yes |
| Scintillator | GOS |
| Dimension | 39×28.5 mm |
| Active Area | 30×22.5 mm |
| Pixel Size | 18.5µm |
| Pixels | 1600×1200 |
| Resolution | 14-20Ip/mm |
| Power Consumption | 600 mW |
Glossary of Key Terminology Related to YR06196
| Term | Definition |
|---|---|
| Digital X-ray | A type of X-ray imaging that uses digital sensors instead of traditional film, enhancing image quality and reducing exposure to radiation. |
| Intraoral X-ray | A dental radiography technique where the X-ray film or sensor is placed inside the mouth to capture detailed images of teeth and surrounding structures. |
| Microfocus Technology | A technology that significantly improves image resolution by using a smaller focus point for the X-ray beam. |
| Filtration | The process of removing low-energy X-rays from the beam, ensuring the quality of the image and minimizing patient exposure. |
| Leak Radiation | The radiation that escapes from the X-ray tube casing, which must be controlled to meet safety standards. |
| Scintillator | A material that emits light when exposed to X-rays, used in digital sensors to convert X-rays into a visible image. |
| CMOS | Complementary Metal-Oxide-Semiconductor, a technology for fabricating electronic circuits and sensors that is commonly used in digital imaging. |
| Pixel Size | The dimension of a single pixel in an image sensor, affecting the resolution and clarity of the final image. |
| Vibration Isolation | The process of reducing vibrations to enhance the stability of imaging equipment, crucial for maintaining image clarity. |
| Power Consumption | The amount of electrical power required for the operation of the YR06196 system, important for energy efficiency considerations. |
Frequently Asked Questions
What are the advantages of using the YR06196 Digital Veterinary Intraoral X-ray System?
The YR06196 offers several advantages, including reduced radiation exposure, high-resolution imaging due to microfocus technology, and enhanced diagnostic capabilities, making it a preferred choice for veterinary practices.
How does the microfocus technology in the YR06196 improve image quality?
Microfocus technology allows for a smaller focal spot, which results in higher image resolution and clarity. This technology enhances the ability to detect fine details in dental radiographs, essential for accurate diagnosis.
What is the significance of total filtration in the YR06196 X-ray system?
Total filtration is crucial as it helps to eliminate low-energy X-rays that do not contribute to image quality but increase radiation dose to the patient. The YR06196’s filtration ensures optimal image quality while keeping radiation exposure minimal.
Can the YR06196 be integrated with digital imaging systems?
Yes, the YR06196 can connect to digital imaging systems, allowing for seamless integration into existing veterinary diagnostic workflows, increasing efficiency and accessibility of patient data.
What should I consider regarding maintenance for the YR06196 system?
Regular maintenance, including checks for alignment, calibration, and functionality of safety features, is essential to ensure the YR06196 operates optimally. Following the manufacturer’s guidelines will help maintain performance and longevity.
How can the user interface of the YR06196 benefit veterinary practitioners?
The YR06196 features a user-friendly digital touch interface that simplifies operation and allows practitioners to quickly adjust exposure settings for various types of dental imaging, enhancing workflow efficiency.
What types of imaging can the YR06196 be used for in veterinary practices?
The YR06196 is primarily used for intraoral imaging but can also be adapted for various applications such as periodontics and endodontics, providing comprehensive diagnostic capabilities in veterinary dentistry.
